90° Bend Metric Compression Straight Tube
| Code PART NO. |
Tube Outer Diameter | Hose Bore | Dimensions | Remarks | ||||
| TUBE O.D | Nominal Inner Diameter DN | Dash Number | L | H | D | L1 | NOTE | |
| 50091-06L-04 50091-10L-05 50091-10L-06 50091-12L-06 50091-12L-08 50091-15-08 50091-18-10 50091-22-10 50091-22-12 50091-22-16 50091-28-16 50091-35-20 |
6 10 10 12 12 15 18 22 22 22 28 35 |
6 8 10 10 13 13 16 16 19 25 25 32 |
4 5 6 6 8 8 10 10 12 16 16 20 |
31 33 36.5 36.5 43.5 43.5 55 55 64 74 74 91.5 |
44 53 55 60 67 69 73 75 86 91.5 93.5 112.5 |
6 10 10 12 12 15 18 22 22 22 28 35 |
22 23 23 25 25 25 26 28 28 28 30 36 |
Light Series (L) |
| 50091-08S-04 50091-08S-05 50091-08S-06 50091-10S-04 50091-12S-04 50091-12S-05 50091-14-06 50091-14-08 50091-16-08 50091-16-10 50091-20-10 50091-20-12 50091-25-12 50091-25-16 50091-30-16 50091-30-20 50091-38-16 50091-38-200 |
8 8 8 10 12 12 14 14 16 16 20 20 25 25 30 30 38 38 |
6 8 10 6 6 8 10 13 13 16 16 19 19 25 25 32 25 32 |
4 5 6 4 4 5 6 8 8 10 10 12 12 16 16 20 16 20 |
30 33 36.5 32 32 33 36.5 43.5 43.5 55 55 64 64 74 74 91.5 74 91.5 |
48 55 58 50 50 60 63 69 70 77.5 83.5 95.5 99.5 103.5 109.5 120.5 115.5 126.5 |
8 8 8 10 12 12 14 14 16 16 20 20 25 25 30 30 38 38 |
24 24 24 23 23 23 29 29 30 30 36 36 40 40 40 44 50 50 |
Heavy Series (S) |
Note: 1. The codes in the table are used for braided hoses. 2. If used for spiral hoses, change the code to 50092-XX-XX.
