90° Elbow Socket Weld Flange
| PART NO. | FLANGE SIZE | TUBE O.D | DIMENSIONS | BOLT | WORKING PRESSURE | ||||||||
| L1 | L2 | L3 | L4 | L5 | L6 | L7 | L8 | D1 | Mpa | ||||
| 3000PSI | |||||||||||||
| 5FLW9-08-18W 5FLW9-08-20W 5FLW9-12-20W 5FLW9-12-22W 5FLW9-12-25W 5FLW9-16-25W 5FLW9-16-28W 5FLW9-16-30W 5FLW9-16-32W 5FLW9-20-32W 5FLW9-20-35W 5FLW9-20-38W 5FLW9-20-42W 5FLW9-24-42W 5FLW9-24-45W 5FLW9-24-48W 5FLW9-24-50W 5FLW9-32-50W 5FLW9-32-55W 5FLW9-32-60W |
1/2″ 1/2″ 3/4″ 3/4″ 3/4″ 1″ 1″ 1″ 1″ 1.1/4″ 1.1/4″ 1.1/4″ 1.1/4″ 1.1/2″ 1.1/2″ 1.1/2″ 1.1/2″ 2″ 2″ 2″ |
18 20 20 22 25 25 28 30 32 32 35 38 42 42 45 48 50 50 55 60 |
17.5 17.5 22.2 22.2 22.2 26.2 26.2 26.2 26.2 30.2 30.2 30.2 30.2 35.7 35.7 35.7 35.7 42.9 42.9 42.9 |
38.1 38.1 47.6 47.6 47.6 52.4 52.4 52.4 52.4 58.7 58.7 58.7 58.7 69.9 69.9 69.9 69.9 77.8 77.8 77.8 |
46 46 52 52 52 59 59 59 59 73 73 73 73 83 83 83 83 97 97 97 |
54 54 65 65 65 70 70 70 70 79 79 79 79 94 94 94 94 102 102 102 |
10 10 10 10 10 12 12 12 12 14 14 14 14 16 16 16 16 18 18 18 |
16 16 19 19 19 19 19 19 19 22 22 22 22 25 25 25 25 25 25 25 |
18 18 22 22 22 28 28 28 28 30 30 30 30 36 36 36 36 44 44 44 |
37 37 38 38 38 43 43 43 43 51 51 51 51 56 56 56 56 65 65 65 |
9 9 11 11 11 11 11 11 11 11 11 11 11 13.5 13.5 13.5 13.5 13.5 13.5 13.5 |
M8X30 M8X30 M10X35 M10X35 M10X35 M10X35 M10X35 M10X35 M10X35 M10X40 M10X40 M10X40 M10X40 M12X45 M12X45 M12X45 M12X45 M12X45 M12X45 M12X45 |
34.5 34.5 34.5 34.5 34.5 34.5 34.5 34.5 34.5 27.6 27.6 27.6 27.6 20.7 20.7 20.7 20.7 20.7 20.7 20.7 |
