45° Bend Metric Ferrule Straight Tube
| Code PART NO. |
Tube Outer Diameter | Hose Bore | Dimensions | Remarks | ||||
| TUBE O.D | Nominal Inner Diameter DN | Dash Number | L | H | D | L1 | NOTE | |
| 50041-06L-04 50041-10L-05 50041-10L-06 50041-12L-06 50041-12L-08 50041-15-08 50041-18-10 50041-22-10 50041-22-12 50041-22-16 50041-28-16 50041-35-20 |
6 10 10 12 12 15 18 22 22 22 28 35 |
6 8 10 10 13 13 16 16 19 25 25 32 |
4 5 6 6 8 8 10 10 12 16 16 20 |
52 54 56 58.5 73 71 85 87 93.5 101 104 119 |
30 30.5 31 34 37 35.5 39.5 42 45.5 46.5 49.5 57.5 |
6 10 10 12 12 15 18 22 22 22 28 35 |
22 23 23 25 25 25 26 28 28 28 30 36 |
Light Series (L) |
| 50041-08S-04 50041-08S-05 50041-08S-06 50041-10S-04 50041-12S-04 50041-12S-05 50041-14-05 50041-14-06 50041-14-08 50041-16-08 50041-16-10 50041-20-10 50041-20-12 50041-25-12 50041-25-16 50041-30-16 50041-30-20 50041-38-16 50041-38-20 |
8 8 8 10 12 12 14 14 14 16 16 20 20 25 25 30 30 38 38 |
6 8 10 6 6 8 8 10 13 13 16 16 19 19 25 25 32 25 32 |
4 5 6 4 4 5 5 6 8 8 10 10 12 12 16 16 20 16 20 |
54 56 58 54 57 59 61 62 74 77 88 93 101 102 110 114 125 119 129 |
30 32 33 31 35 35.5 37 37.5 38.5 41.5 43 48 52.5 54 55 59.5 63.5 63.5 68 |
8 8 8 10 12 12 14 14 14 16 16 20 20 25 25 30 30 38 38 |
24 24 24 23 25 25 29 29 29 30 30 36 36 40 40 44 44 50 50 |
Heavy Series (S) |
