Product Description

90° Elbow ORFS Male O-Ring / Metric Thread Male Captive Seal

PART NO.	THREAD		DIMENSIONS				WEIGHT	WORKING PRESSURE
	T1	T2	L1	L2	1	S2	g
1FH9-04-12OG 1FH9-04-140G 1FH9-06-12OG 1FH9-06-14OG 1FH9-06-16OG 1FH9-08-14OG\| 1FH9-08-18OG 1FH9-08-22OG 1FH9-10-18OG 1FH9-10-22OG 1FH9-12-22OG\| 1FH9-12-27OG\| 1FH9-16-33OG 1FH9-20-42OG 1FH9-24-48OG	9/16″X18 9/16″X18 11/16″X16 11/16″X16 11/16″X16 13/16″X16 13/16″X16 13/16″X16 1″X14 1″X14 1.3/16″X12 1.3/16X12 1.7/16″X12 1.11/16X12 2″X12	M12X1.5 M14X1.5 M12X1.5 M14X1.5 M16X1.5 M14X1.5 M18X1.5 M22X1.5 M18X1.5 M22X1.5 M22X1.5 M27X2 M33X2 M42X2 M48X2	21.5 23.5 25 25 25 28 28 31 33.5 33.5 37.5 37.5 41.5 44.5 49	33 35.5 35.5 35.5 37.5 36 41 49 47.5 49 49.5 55.5 59.5 63 71.5	14 17 19 19 19 19 19 22 27 27 30 30 36 41 50	17 19 17 19 22 19 24 27 24 27 27 32 41 50 55	51 68 65 77 93 98 117 183 172 223 278 358 555 742 1035\|	31.5 31.5 31.5 31.5 25 31.5 25 25 25 25 25 16 16 16 16
