45° bend metric internal thread plane reference REF.GB/T9065.3
| Code PART NO. |
Thread T | Hose Bore | Dimensions | |||
| THREAD T | Nominal Inner Diameter DN | Dash Number | L | H | S1 | |
| 20291-14-04T 20291-14-05 20291-16-05T 20291-16-06 20291-18-06T 20291-22-08T 20291-27-10T 20291-30-12T 20291-39-16T 20291-45-20T 20291-52-24T 20291-64-32T |
M14X1.5 M14X1.5 M16X1.5 M16X1.5 M18X1.5 M22X1.5 M27X1.5 M30X1.5 M39X2 M45X2 M52X2 M64X2 |
6 8 8 10 10 13 16 19 25 32 38 51 |
4 5 5 6 6 8 10 12 16 20 24 32 |
32 33 32.5 36.5 36.5 43.5 55 63 74 91.5 109 129 |
28.5 33.5 35 37 39 43.5 52 58 68.5 78.5 92 113.3 |
17 19 19 22 22 27 32 36 46 55 60 75 |
Note: 1. The codes in the table are used for braided hoses. 2. If used for wrapped hoses, change the code to 20292-XX-XX.
