High Pressure BSP Banjo Elastic Seal
| PART NO. | THREAD | TUBE O.D | DIMENSIONS | WORKING PRESSURE | |||||||||||
| T1 | T2 | TUDE O.D. | L1 | L2 | L3 | L4 | L5 | L6 | L7 | D1 | 1 | S2 | S3 | Mpa | |
| 1C1-12-B02KDS 1C1-14-B04KDS 1C1-16-B04KDS 1C1-18-B06KDS 1C1-22-B08KDS 1C1-26-B08KDS 1C1-30-B12KDS 1C1-36-B16KDS 1C1-45-B20KDS 1C1-52-B24KDS 1D1-14-B04KDS 1D1-16-B04KDS 1D1-18-B06KDS 1D1-20-B06KDS 1D1-22-B08KDS 1D1-24-B08KDS 1D1-30-B12KDS 1D1-36-B16KDS 1D1-42-B20KDS 1D1-52-B24KDS |
M12X1.5 M14X1.5 M16X1.5 M18X1.5 M22X1.5 M26X1.5 M30X2 M36X2 M45X2 M52X2 M14X1.5 M16X1.5 M18X1.5 M20X1.5 M22X1.5 M24X1.5 M30X2 M36X2 M42X2 M52X2 |
G1/8″X28 G1/4″ X19 G1/4″ X19 G3/8″ X19 G1/2″X14 G1/2″ X14 G3/4″ X14 G1 ” X11 G1.1/4″X11 G1.1/2″X11 G1/4″ X19 G1/4″ X19 G3/8″X19 G3/8″ X19 G1/2 “X14 G1/2 ” X14 G3/4″ X14 G1″ X11 G1.1/4″ X11 G1.1/2″X11 |
6 8 10 12 15 18 22 28 35 42 6 8 10 12 14 16 20 25 30 38 |
19 21.5 22.5 25 28.5 28.5 35 39.5 46.5 51.5 23.5 23.5 26 26 30.5 30.5 37 43.5 50.5 57.5 |
12 14.5 15.5 18 21.5 21 27.5 32 36 40.5 16.5 16.5 18.5 18.5 22.5 22 26.5 31.5 37 41.5 |
10.5 14 14 16.5 21.5 21.5 24 30.5 35.5 40.5 14 14 16.5 16.5 21.5 21.5 24 30.5 35.5 40.5 |
8 12 12 12 14 14 16 18 20 22 12 12 12 12 15 14 16 18 20 22 |
24 30 30 36 45 45 53 66 76 87 30 30 36 36 45 45 53 66 76 87 |
27 29 30 33 37 37 44 49 58 63 31 31 35 35 40 40 48 56 64 72 |
2.5 3 3 3 4.5 4.5 3.5 3.5 3.5 3.5 3 3 3 3 4.5 4.5 3.5 3.5 3.5 3.5 |
14.9 18.9 18.9 21.9 26.9 26.9 32.9 39.9 49.9 55.9 18.9 18.9 21.9 21.9 26.9 26.9 32.9 39.9 49.9 55.9 |
17 22 22 27 32 32 41 50 60 70 22 22 27 27 32 32 41 50 60 70 |
17 19 19 24 30 30 36 46 55 60 19 19 24 24 30 30 36 46 55 60 |
14 17 19 22 27 32 36 41 50 60 17 19 22 24 27 30 36 46 50 60 |
31.5 31.5 31.5 31.5 31.5 31.5 16 16 16 16 40 40 40 40 40 31.5 31.5 25 16 16 |
Note:In case if you are interested to order the adapter in complete set with cutting ring and nut,it is necessary to insert suffix”RN” after our ,for example 1CI-30-B12KDS RN.
